Trane KIT01052 Motor Mounting Bracket Kit | 48 Frame OEM

The Trane KIT01052 is a genuine factory-authorized motor mounting bracket kit (belly band) designed specifically for Trane and American Standard 48-frame blower motors. This heavy-duty mounting solution is engineered to provide a secure, vibration-resistant fit for direct-drive blower applications in furnaces and air handlers.

This kit consists of a direct-drive belly band mounting ring set featuring three precision-welded ears. Each ear is designed with dual mounting holes, providing the flexibility needed for easy alignment and installation across various blower housing configurations.



Compatibility & Cross-Reference

The KIT01052 is the official service replacement for several legacy mounting kits. It is the required OEM hardware if your system documentation or previous bracket lists:

  • Replaces Trane / American Standard P/Ns: KIT02414, KIT17764
  • Common Motor Pairings: Specifically designed for use with the MOT18971 blower motor and a wide range of other Trane 48-frame motors.
  • Verification: If you are unsure if this is the correct mounting hardware for your furnace or air handler, we recommend contacting us with the model and serial number found on the rating plate inside the wall of your system.

Why Choose Genuine Trane Mounting Hardware?

  • Universal 48-Frame Fit: Engineered to wrap securely around standard 5-5/8" diameter (48 frame) motors.
  • Vibration Dampening: Built to maintain high-torque motors in a fixed position, reducing operational noise and preventing premature motor wear.
  • Corrosion Resistant: Durable construction ensures the bracket maintains its structural integrity in high-moisture HVAC environments.
  • Ease of Installation: The dual-hole ear design allows for a "drop-in" fit in many existing blower housings without the need for drilling or modification.

Shipping & Order Details

  • Free Shipping: We offer free shipping on this item for all orders delivered within the United States.
  • Authenticity Guaranteed: Shorty’s HVAC Supplies only stocks brand-new, genuine Trane parts to ensure the safety and longevity of your equipment.

Technical Specifications

FeatureDetail
Part NumberKIT01052
TypeBelly Band / Mounting Ring Set
Motor Frame Size48 Frame (5-5/8" Diameter)
Mounting Style3-Ear Direct Drive
Hole ConfigurationDual-Hole Welded Ears
Included HardwareMounting Rings and Required Hardware

$147.00

Add to Cart:
Always Free Shipping
  • Model: KIT01052
  • Manufactured by: Trane
